JAC vacuum sweeper, street sweeper truck

JAC vacuum sweeper, street sweeper truck

JAC Street Sweeper Truck Engine Model WP3Q130E50 ,96 kw ,130HP, 2970CC

JDFtruck is the Chinese Street Sweeper Truck manufacturer JAC Street Sweeper Truck quality have beed approved by CCC and ISO9001:2000 quality certificate ,Contact us: jndfa@hotmail.com.

Our JAC Street Sweeper Truck have a wide range of chassis brand optional , different load volume to choose .

Vehicle Name: JAC  vacuum sweeper Vehicle Category: JAC  Street Sweeper Truck
Chinese Brand: JAC  JDFTRUCK English brand : JAC  JDFTRUCK
Notice batch : Exemption: No
Engine Engine Manufacturer Displacement (ml) Power (kw)
WP3Q130E50 Weichai power yangzhou diesel engine co., LTD 2970 96
Engine brand : HOWO Fuel type: Diesel (mm)
Dimensions: 6148,6200×2050×2510(mm) Compartment Size : × × (mm)
The total mass : 7340Kg) Payload: 0

.

Curb weight: 5130(Kg) Rated Quality: 2080(Kg)
Quality Trailer : (kg) Semitrailer saddle :
Rated capacity : ( People ) Cab seats : 3( People )
Approach / departure angle : 27/10(°) Front / rear overhang : 1085/1755(mm)
Axle load: 2630/4710 Wheelbase: 3360,3308(mm)
Number of axes: 2 Maximum speed: 90(km/h)
Fuel consumption: Spring: 8/4+6,11/9+7
Number of tires : 6 Tire Size: 7.00R16,7.00-16
Front track: 1440 Rear track: 1425,1395
Steering Type : Steering wheel Starting method:
Chassis Emission standard: GB3847-2005, GB17691-2005 National
Transmission Type: Steering wheel According to the standard :
Logo Enterprises : JDFtruck Release date: 20160919
Vehicle Notes : JAC vacuum sweeper, street sweeper truck

JAC vacuum sweeper, street sweeper truck Chassis

JAC  truck chassis |JAC  truck chassis HFC1070P93K1C3ZV
Company Name : JAC Motor Co., Ltd.
Chassis Type: HFC1070P93K1C3ZV Chassis Category: II
Product Name: Truck chassis Product Brand: JAC
Zip Code: 250002 Catalog number : 3
Specifications: Length:5815,5773  Width:1860,1830Height: 2180
Fuel Type: Diesel fuel According to the standard : GB17691-2005(Ⅳ),GB3847-2005
Steering Type : Steering wheel
Number of axes: 2 Wheelbase: 3360,3308
Spring: 8/4+6,11/9+7 Number of tires : 6
Tire Size: 7.00R16,7.00-16 Tread : Front track 1600,1800     Rear track 1535,1595
The total mass : 7340
Curb weight: 5130 Quality Trailer :
Semitrailer saddle : Front passenger : 2+3
Close to the departure angle: 27/10 Rear suspension : 1085/1755
Maximum speed: 90

JAC vacuum sweeper, street sweeper truck

JAC Street Sweeper Truck   chassis JAC  Street Sweeper Truck  chassis HFC1070P93K1C3ZV Engine Specification
Engine Model Engine Manufacturer Displacement (ML) Power (ML)
WP3Q130E50 Weichai power yangzhou diesel engine co., LTD

2970

96
