Project Description
ISUZU Sweeper Road Clean Truck,Sweeping Truck
ISUZU Sweeper Road Clean Truck,Sweeping Truck
ISUZU Street Sweeper Truck Engine Model 4KH1-TCG40 , 88kw ,119HP, 2999CC
JDFtruck is the Chinese Street Sweeper Truck manufacturer ISUZU Street Sweeper Truck quality have beed approved by CCC and ISO9001:2000 quality certificate ,Contact us: jndfa@hotmail.com.
Our ISUZU Street Sweeper Truck have a wide range of chassis brand optional , different load volume to choose .
ISUZU Sweeper Road Clean Truck,Sweeping Truck
| Vehicle Name: | ISUZU vacuum sweeper | Vehicle Category: | ISUZU Street Sweeper Truck | ||
| Chinese Brand: | ISUZU JDFTRUCK | English brand : | ISUZU JDFTRUCK | ||
| Notice batch : | 275 | Exemption: | No | ||
| Engine | Engine Manufacturer | Displacement (ml) | Power (kw) | ||
| 4KH1-TCG40 | chongqing ISUZU | 2999 | 88 | ||
| Engine brand : | ISUZU | Fuel type: | Diesel (mm) | ||
| Dimensions: | 6200×2010×2530(mm) | Compartment Size : | × × (mm) | ||
| The total mass : | 7300(Kg) | Payload: | 0 | ||
| Curb weight: | 5050(Kg) | Rated Quality: | 2120(Kg) | ||
| Quality Trailer : | (kg) | Semitrailer saddle : | |||
| Rated capacity : | ( People ) | Cab seats : | 2( People ) | ||
| Approach / departure angle : | 24/12(°) | Front / rear overhang : | 1015/825（mm) | ||
| Axle load: | 2580/4720 | Wheelbase: | 3360(mm) | ||
| Number of axes: | 2 | Maximum speed: | 105(km/h) | ||
| Fuel consumption: | Spring: | 8/6+5 | |||
| Number of tires : | 6 | Tire Size: | 7.00-16 14PR,7.00R16 14PR | ||
| Front track: | 1504 | Rear track: | 1425 | ||
| Steering Type : | Steering wheel | Starting method: | |||
| Chassis Emission standard: | GB3847-2005, GB17691-2005 National | ||||
| Transmission Type: | Steering wheel | According to the standard : | |||
| Vin Vehicle Identification Number: | LWLDAA1G××××××××× | ||||
| Logo Enterprises : | JDFtruck | Release date: | 20160919 | ||
| Vehicle Notes : | Along with the chassis options widen the front bumper; Profile interference protection device and working device, so the exemption; After the lower protective device material: Q235, connection mode: welding and bolt connection, section size (width x height) : 50 * 100 (mm), and height from the ground: 410 mm. | ||||
ISUZU Sweeper Road Clean Truck,Sweeping Truck Chassis
| DongFeng truck chassis |DongFeng truck chassisQL1070A1HAY | ||||
| Company Name : | ISUZU Motor Co., Ltd. | |||
| Chassis Type: | QL1070A1HAY | Chassis Category: | II | |
| Product Name: | Truck chassis | Product Brand: | ISUZU | |
| Zip Code: | 400052 | Catalog number : | 3 | |
| Specifications: | Length:5900 Width:1880 Height: 2160 | |||
| Fuel Type: | Diesel fuel | According to the standard : | GB17691-2005(Ⅳ),GB3847-2005 | |
| Steering Type : | Steering wheel | |||
| Number of axes: | 2 | Wheelbase: | 3360 | |
| Spring: | 8/6+5 | Number of tires : | 6 | |
| Tire Size: | 7.00-16 14PR,7.00R16 14PR | Tread : | Front track1504 Rear track 1425 | |
| The total mass : | 7300 | |||
| Curb weight: | 1900 | Quality Trailer : | ||
| Semitrailer saddle : | Front passenger : | 2 | ||
| Close to the departure angle: | 24/16 | Rear suspension : | 1015/1525 | |
| Maximum speed: | 105 | |||
ISUZU Sweeper Road Clean Truck,Sweeping Truck
| ISUZU Street Sweeper Truck chassis ISUZU Street Sweeper Truck chassis QL1070A1HAY Engine Specification | |||
| Engine Model | Engine Manufacturer | Displacement (ML) | Power (ML) |
| ISUZU | ISUZU | 2999 | 88 |
| Identification code : | LWLDAA1G××××××××× | ||
ISUZU Sweeper Road Clean Truck,Sweeping Truck
