Project Description
DongFeng JinBa Road Wrecker Truck,Recovery Truck
DongFeng JinBa Road Wrecker Truck,Recovery Truck
DongFeng Recovery Truck Engine Model YC4F115-304, 85kw ,184HP,2659CC
JDFtruck Is The ChineseDongFeng Recovery Truck Manufacturer DongFeng Recovery Truck Quality Have Beed Approved By CCC And ISO9001:2000 Quality certificate ,Contact us: jndfa@hotmail.com.
Our DongFeng Recovery Truck Have A Wide Range Of Chassis Brand Optional , Different Load Volume To Choose .
| Vehicle Name: | DongFeng Recovery Truck | Vehicle Category: | DongFeng Recovery Truck | ||
| Chinese Brand: | DongFeng JDFTRUCK | English brand : | DongFeng JDFTRUCK | ||
| Notice batch : | Exemption: | No | |||
| Engine | Engine Manufacturer | Displacement (ml) | Power (kw) | ||
| YC4F115-30 | Guangxi yuchai machinery co., LTD | 2659 | 85 | ||
| Engine brand : | DongFeng | Fuel type: | Diesel (mm) | ||
| Dimensions: | 5995*1970*2400,2900 (mm) | Compartment Size : | × × (mm) | ||
| The total mass : | 7495(Kg) | Payload: | 0 | ||
| Curb weight: | (Kg) | Rated Quality: | (Kg) | ||
| Quality Trailer : | (kg) | Semitrailer saddle : | |||
| Rated capacity : | ( People ) | Cab seats : | 3( People ) | ||
| Approach / departure angle : | 20/14(°) | Front / rear overhang : | 1115/1580(mm) | ||
| Axle load: | Wheelbase: | 4500,4700(mm) |
| Number of axes: | 2 | Maximum speed: | 80(km/h) | ||
| Fuel consumption: | Spring: | 8/9+5 | |||
| Number of tires : | 6 | Tire Size: | 7.00R16,7.00-16 | ||
| Front track: | 1586 | Rear track: | 1530 | ||
| Steering Type : | Steering wheel | Starting method: | |||
| Chassis Emission standard: | GB3847-2005, GB17691-2005 National | ||||
| Transmission Type: | Steering wheel | According to the standard : | |||
| Logo Enterprises : | JDFtruck | Release date: |
|
||
| Vehicle Notes : | DongFeng JinBa Road Wrecker Truck,Recovery Truck | ||||
DongFeng JinBa Road Wrecker Truck,Recovery Truck Chassis
| DongFeng truck chassis |DongFeng truck chassis EQ1070T35DJ3AC | ||||
| Company Name : | DongFeng Motor Co., Ltd. | |||
| Chassis Type: | EQ1070T35DJ3AC | Chassis Category: | II | |
| Product Name: | Truck chassis | Product Brand: | DongFeng | |
| Zip Code: | Catalog number : | 3 | ||
| Fuel Type: | Diesel fuel | According to the standard : | GB3847-2005(Ⅳ),GB17691-2005 | |
| Steering Type : | Steering wheel | |||
| Number of axes: | 2 | Wheelbase: | 3300 | |
| Spring: | 8/9+5 | Number of tires : | 6 | |
| Tire Size: | 7.00R16,7.00-16 | Tread : | Front track1586Rear track1530 | |
| The total mass : | 7495 | |||
| Curb weight: | Quality Trailer : | |||
| Semitrailer saddle : | Front passenger : | 3 | ||
| Close to the departure angle: | Front / Rear suspension : | 1115/1580 | ||
| Maximum speed: | 80 | |||
| DongFeng JinBa Road Wrecker Truck,Recovery Truck | ||||
DongFeng JinBa Road Wrecker Truck,Recovery Truck
| DongFeng Recovery Truck chassis DongFeng Recovery Truck chassis EQ1070T35DJ3AC Engine Specification | |||
| Engine Model | Engine Manufacturer | Displacement (ML) | Power (ML) |
| YC4F115-30 | Guangxi yuchai machinery co., LTD | 2659 | 85 |
