DongFeng 6X4 Road Wrecker Truck,Recovery Truck
DongFeng 6X4 Road Wrecker Truck,Recovery Truck
DongFeng Recovery Truck Engine Model ISDe185 30, 136kw ,184HP,6700CC
JDFtruck Is The ChineseDongFeng Recovery Truck Manufacturer DongFeng Recovery Truck Quality Have Beed Approved By CCC And ISO9001:2000 Quality certificate ,Contact us: jndfa@hotmail.com.
Our DongFeng Recovery Truck Have A Wide Range Of Chassis Brand Optional , Different Load Volume To Choose .
| Vehicle Name: |
DongFeng Recovery Truck |
Vehicle Category: |
DongFeng Recovery Truck |
| Chinese Brand: |
DongFeng JDFTRUCK |
English brand : |
DongFeng JDFTRUCK |
| Notice batch : |
189 |
Exemption: |
No |
| Engine |
Engine Manufacturer |
Displacement (ml) |
Power (kw) |
| ISDe185 30 |
Dongfeng cummins engine co., LTD |
6700 |
136 |
| Engine brand : |
DongFeng |
Fuel type: |
Diesel (mm) |
| Dimensions: |
7440×2498×2920(mm) |
Compartment Size : |
× × (mm) |
| The total mass : |
15600(Kg) |
Payload: |
0 |
| Curb weight: |
10705(Kg) |
Rated Quality: |
(Kg) |
| Quality Trailer : |
(kg) |
Semitrailer saddle : |
|
| Rated capacity : |
( People ) |
Cab seats : |
3( People ) |
| Approach / departure angle : |
27/16(°) |
Front / rear overhang : |
1250/1490(mm) |
| Axle load: |
5890/9710 |
|
Wheelbase: |
|
4500,4700(mm) |
| Number of axes: |
2 |
Maximum speed: |
80(km/h) |
| Fuel consumption: |
|
Spring: |
9/10+8 |
| Number of tires : |
6 |
Tire Size: |
9.00-20,9.00R20,10.00-20,10.00R20 |
| Front track: |
1940 |
Rear track: |
1860 |
| Steering Type : |
Steering wheel |
Starting method: |
|
| Chassis Emission standard: |
GB3847-2005, GB17691-2005 National |
| Transmission Type: |
Steering wheel |
According to the standard : |
|
| Logo Enterprises : |
JDFtruck |
Release date: |
20160919 |
| Vehicle Notes : |
DongFeng 6X4 Road Wrecker Truck,Recovery Truck |
DongFeng 6X4 Road Wrecker Truck,Recovery Truck Chassis
| DongFeng truck chassis |DongFeng truck chassis EQ5160GKJ |
| Company Name : |
DongFeng Motor Co., Ltd. |
|
| Chassis Type: |
EQ5160GKJ |
Chassis Category: |
II |
|
| Product Name: |
Truck chassis |
Product Brand: |
DongFeng |
|
| Zip Code: |
|
Catalog number : |
3 |
|
| Fuel Type: |
Diesel fuel |
According to the standard : |
GB3847-2005(Ⅳ),GB17691-2005 |
|
| Steering Type : |
Steering wheel |
|
| Number of axes: |
2 |
Wheelbase: |
3300 |
|
| Spring: |
9/10+8 |
Number of tires : |
6 |
|
| Tire Size: |
9.00-20,9.00R20,10.00-20,10.00R20 |
Tread : |
Front track 1940Rear track 1860 |
|
| The total mass : |
15600 |
|
| Curb weight: |
10705 |
Quality Trailer : |
|
|
| Semitrailer saddle : |
|
Front passenger : |
3 |
|
| Close to the departure angle: |
|
Front / Rear suspension : |
1250/1490 |
|
| Maximum speed: |
80 |
|
|
DongFeng 6X4 Road Wrecker Truck,Recovery Truck |
DongFeng 6X4 Road Wrecker Truck,Recovery Truck
| DongFeng Recovery Truck chassis DongFeng Recovery Truck chassis EQ1051TJ35D3 Engine Specification |
| Engine Model |
Engine Manufacturer |
Displacement (ML) |
Power (ML) |
| ISDe185 30
|
DongFeng Motor Co., Ltd. |
6700 |
136 |
