Basic information
Driving type: 6×4
Wheelbase: 3350 + 1400mm
Engine: Foton Cummins x13ns6b560
Transmission: fast c12jsdqxl260ta al
Body length: 6.885m
Body width: 2.55m
Body height: 3.12M
Front track: 2020mm
Rear track: 1858 / 1858mm
Vehicle weight: 8.87 tons
Total mass: 25 tons
Total traction mass: 40t
Maximum speed: 120km / h
Market segments: iron powder, steel transportation, sand and stone transportation
Tonnage grade: heavy truck
Remarks: steel air storage tank, integral fender, lightweight front lower protection, 180 a battery
Engine parameters
Engine model: Foton Cummins x13ns6b560
Engine brand: Foton Cummins
Number of cylinders: 6
Fuel type: Diesel
Cylinder arrangement: in-line
Displacement: 12.9l
Emission standard: National VI
Maximum horsepower: 560 horsepower
Maximum output power: 412kw
Maximum torque: 2600n · M
Maximum torque speed: 1000-1400rpm
Rated speed: 1800rpm
Cab parameters
Cab: flat roof
Cab suspension: four point airbag suspension
Number of passengers allowed: 2
Number of seats: half a row
Cab lifting: Electric
Driver’s seat form: airbag shock absorbing seat
Transmission parameters
Transmission model: fast c12jsdqxl260ta
Gearbox brand: fast
Shift mode: Manual
Forward gear: 12th gear
Number of reverse gears: 2 tyre
Number of tires: 10
Tire type: 12r22.5
tank Oil tank / air tank capacity: 700L
Chassis parameters
Front axle Description: 6.5T
Rear axle Description: 469 rear axle
Allowable load of rear axle: 18000 (two axle group) kg
Allowable load of front axle: 7000kg
Number of springs: 2 / 4, 3 / 6, 8 / 12, 2 / -, 3/- Saddle: 90#
